Vandal resistant & IP65 waterproofed, Ideal for outdoor installation.
Large storage capacity up to 3,000 fingerprints, 30,000 proximity cards and 100,000 logs.
Able to connect specially designed FR1200 fingerprint slave reader.
Combine master and slave system to secure the entrance and exit with dual biometric authentication and by RS485.
Support Anti-passback to maximize security level.
Easy to integrate with existing system. Wiegand output is connectable to most of the access control panel brands.
Provide various types of alarms, such as, door sensor alarm, duress alarm etc.
Free Pull SDK available for integration.
Catégorie : Terminaux de contrôle d'accès
Disponibilité : En Stock
Fabricant : ZkTeco
Model | MA500 |
Software | ZKAccess3.5 |
SDK | New PULL SDK |
Fingerprint Sensor | Optical sensor with protective cover |
Algorithm Version | ZKFinger VX10.0 |
Fingerprint Capacity | 3,000 |
Card Capacity | 30,000 |
Log Capacity | 100,000 |
RF Card | EM(standard)/Mifare(optional) |
Authentication Method | FP only, RF only, PIN only, FP/RF/PIN, PIN&FP, PIN & RF |
Access Control Interface | Electric lock, Door sensor, Alarm, Exit button |
Communication | TCP/IP, RS485 |
Wiegand Signal | Wiegand out |
Ingress Protection Rate | IP65 |
Power Supply | 12VDC 3A |
Operating Temperature | 0°C – 45°C |
Dimensions (W×H×D) | 83mm×127.5mm×74mm |
